R710 Indoor Access Point

Name: R710 Indoor Access Point
Brand: Ruckus

Indoor 802.11ac wave 2 4x4:4 wi-fi ap

Bandwidth-hungry voice and video applications. Internet of Things (IoT) connections. An explosion of new devices and content. With these kinds of demands, organizations in every industry need more from their Wi-Fi. But with hundreds of devices and nonstop wireless noise and interference, busy indoor spaces can make challenging wireless environments.

The Ruckus R710 is a premier indoor access point, delivering industry-leading performance and reliability in the most demanding high-density locations. With data rates up to 800Mbps (2.4GHz) and 1.733Gbps (5GHz), the R710 delivers the highest available throughput for Wi-Fi clients.

The R710 delivers reliable, high-performance connectivity in schools, universities, public venues, hotels, conference centers, and other busy indoor spaces. The perfect choice for data-intensive streaming multimedia applications, it delivers picture-perfect HD-quality IP video, while supporting voice and data applications with stringent quality-of-service requirements.

The R710 802.11ac Wave 2 Wi-Fi AP incorporates patented technologies found only in the Ruckus Wi-Fi portfolio.

Download spec sheet Ask about this device Available to rent

Ideal forHealthcare Logistics Retail Warehousing

Backed by ITSSA CareRepairs, hot swops and support for the life of the device.

Specifications

R710 Indoor Access Point at a glance

With MultiUser MIMO (MU-MIMO) connectivity, the R710 can simultaneously transmit to multiple client devices, drastically improving RF efficiency, overall throughput, and availability—even for non-Wave 2 clients. The R710 also features a USB port for hosting IoT devices such as Bluetooth Low Energy (BLE) beacons, and dual Gigabit Ethernet ports that support Link Aggregation for higher-capacity backhaul to the switch. The R710 supports up to 512 clients per AP and features capacity-based admission control to prevent APs from getting congested with too many attached devices.

Whether you’re deploying ten or ten thousand APs, the R710 is also easy to manage through Ruckus’ appliance, virtual and cloud management options.

WI-FI STANDARDS IEEE: 802.11a/b/g/n/ac Wave 2
PEAK PHY RATES: 2.4GHz: 600Mbps 5GHz: 1733Mbps
CLIENT CAPACITY: Up to 512 clients per AP
ANTENNA OPTIMIZATION: BeamFlex+ Polarization Diversity with Maximal Ratio Combining (PD-MRC)
WI-FI CHANNEL MANAGEMENT: n/a
MESH: SmartMesh™ wireless meshing technology. Self-healing Mesh
USB: 1 USB 2.0 port, Type A
ETHERNET: Two 1Gbps Ethernet ports Power over Ethernet (802.3af/at/bt) with Category 5/5e/6 cable Link Aggregation (LACP)
OPERATING TEMPERATURE: -4ºC (-14ºF) to 60ºC (140ºF)

Extended coverage with patented BeamFlex+ utilizing multi-directional antenna patterns.
Improve throughput with ChannelFly, which dynamically finds less congested Wi-Fi channels to use.

Specifications are supplied by the manufacturer and can change. Our team will confirm the exact configuration with your quote.
